Tire Size Calculator

What This Calculator Really Does

A tire size like P215/60R16 is a compact engineering spec: tread width in millimeters, sidewall as a percentage of that width, and rim diameter in inches. This calculator decodes it into sidewall height and overall tire diameter — the two numbers that decide clearance, gearing and speedometer accuracy.

The diameter matters most when changing sizes. A taller tire makes the speedometer under-read (the wheel turns fewer times per mile), a shorter one over-reads it. Knowing the percent difference before you buy saves an expensive mistake.

Everything runs locally in your browser: no vehicle data uploaded, nothing tracked, offline after the first visit.

The Formulas, Explained Plainly

Sidewall height = section width × aspect ratio ÷ 100

Overall diameter = rim diameter + 2 × sidewall

• Section width — the first number (215), in millimeters.
• Aspect ratio — the second number (60), sidewall height as a percent of width — not a millimeter figure.
• Rim diameter — the third number (16), in inches, converted to millimeters (× 25.4).

Revolutions per mile ≈ 1,609,344 mm ÷ diameter(mm) ÷ π — the number your speedometer and odometer actually count.

How to Use It — In Order

1. Read the size off the sidewall — e.g. P215/60R16, ignoring the P (passenger) class letter.
2. Enter width, aspect ratio and rim — each field is labeled with its unit.
3. Read sidewall and diameter — the physical envelope of the tire.
4. Enter the alternative size — the candidate replacement.
5. Compare diameters — keep the difference within roughly ±3% to limit speedometer error and clearance risk.
6. Confirm against the door-jamb placard — the manufacturer's approved sizes override any general rule.

Worked Example, Verified by Hand

P215/60R16:

1. Sidewall: 215 × 0.60 = 129 mm.
2. Rim: 16 × 25.4 = 406.4 mm.
3. Diameter: 406.4 + 2 × 129 = 664.4 mm ≈ 26.16 inches.
4. Revolutions per mile: 1,609,344 ÷ 664.4 ÷ 3.1416 ≈ 771.

Swap to 225/50R17 (rim 431.8 mm, sidewall 112.5 mm): diameter = 656.8 mm — 1.1% smaller. The speedometer would over-read by about the same fraction; within the usual ±3% tolerance.

Common Mistakes to Avoid

• Reading the aspect ratio as millimeters — 60 means 60% of the width, so a 215/60 sidewall is 129 mm, not 60 mm.
• Mixing inch and millimeter fields — rim in inches, width and sidewall in millimeters; unit slips scale the answer by 25.4.
• Ignoring diameter drift on upgrades — beyond roughly ±3%, expect speedometer error, gearing change and possible rubbing.
• Comparing width alone — a wider tire with a lower aspect ratio can be the same diameter; the envelope is what clears the fender.
• Forgetting load and speed ratings — size is only part of fitment; the placard ratings matter for safety.

Limitations

• Nominal dimensions — actual mounted width varies with rim width; manufacturers publish measuring-rim specifics.
• No load/inflation tables — the calculator sizes geometry, not capacity.
• Plus-sizing legality and insurance implications are your jurisdiction's call, not the calculator's.

Expected Accuracy

Exact arithmetic (× 0.60, × 25.4, + 2 × sidewall) at full precision — matching a hand calculation to the tenth of a millimeter. Nominal-vs-mounted differences are tire-industry reality, not math error.

Privacy — Your Data Never Leaves This Device

No vehicle or tire data is stored or sent — computation is entirely local, and the tool works offline.

Related Tools & Guides

Natural next steps from Tire Size:

• All Auto & Transport Calculators
• Mileage Calculator — bigger diameter changes the odometer reading
• Stopping Distance Calculator — grip and size interact
• Car Loan EMI Calculator — budgeting the full upgrade
• Fuel Cost Calculator

Sources & Standards

The metric tire code follows standard industry sizing conventions; unit conversions use exact international definitions.

• NIST Weights & Measures — inch/millimeter definitions

Bottom Line

Width × ratio gives the sidewall; rim plus two sidewalls gives the diameter — and keeping diameters within ±3% is what keeps speedometers, gearing and fenders happy.
