Wire Gauge (AWG) Converter
Convert AWG to mm and mm²
🔒 Runs locally · Method · · Disclaimer · Wire Gauge (AWG) Converter
Wire Gauge (AWG) Converter is built for converting AWG to mm and mm² — fast, free, and private. Enter AWG in any order — Wire Gauge (AWG) recalculates on every edit. The answer from Wire Gauge (AWG) arrives with its working attached. Wire Gauge (AWG) works for one check or many. Nothing is uploaded while Wire Gauge (AWG) works, and the figures stay put. Wire Gauge (AWG) is part of the Unit Conversion collection on CalcProMaster, alongside awg to mm converter wire gauge diameter area, free online wire gauge (awg) converter and more. Keep Wire Gauge (AWG) bookmarked for next time. Start with Wire Gauge (AWG); the first number takes seconds.
What 14 AWG measures
A 14 AWG conductor is 1.628 mm in diameter and 2.08 mm² in cross-section. That is the size behind most 15 A household branch circuits in North America.
The gauge number runs backwards from what you would expect: as AWG rises by six, the wire diameter roughly halves. Going the other way, AWG 14 is 0.0641 inches — the figure printed on the spool in the US.
The conversion formula
AWG is defined by a geometric series, not a table lookup: d (mm) = 0.127 × 92(36 − n)/39, where n is the gauge number.
For n = 14 the exponent is (36 − 14)/39 = 0.5641. 920.5641 = 12.82, and 0.127 × 12.82 = 1.628 mm. The cross-section follows from the circle area: π × (1.628/2)² = 2.08 mm².
Worked example, step by step
d = 0.127 × 92(36−14)/39
d = 0.127 × 920.5641 = 0.127 × 12.82 = 1.628 mm
Area = πd²/4 = π × 2.651 / 4 = 2.08 mm²
In inches: 1.628 ÷ 25.4 = 0.0641 in
The sizes people actually ask about
- AWG 18 — 1.024 mm, 0.823 mm². Lamp cord, low-current electronics.
- AWG 16 — 1.291 mm, 1.31 mm². Extension leads, automotive runs.
- AWG 14 — 1.628 mm, 2.08 mm². 15 A lighting and receptacle circuits.
- AWG 12 — 2.053 mm, 3.31 mm². 20 A kitchen and workshop circuits.
- AWG 10 — 2.588 mm, 5.26 mm². 30 A dryers and heavy feeders.
Where the number stops being a current rating
Diameter and area are geometry; ampacity is not. The current a wire can carry depends on insulation temperature rating, how many conductors share a conduit, ambient temperature and installation method. 14 AWG copper on a 60 °C insulation is good for 15 A, but the same wire bundled with others in a hot ceiling is derated. Use the gauge figure to buy and measure, and the local code table to size.
Mistakes worth avoiding
- Reading the exponent backwards. It is (36 − n), not (n − 36); a negative exponent gives a wire thinner than a hair for 14 AWG.
- Confusing mm² with mm. Cross-section is area; diameter is a length. A 4 mm² cable is not 4 mm across.
- Assuming the metric equivalent is exact. “2.5 mm²” installation cable is sold to its own standard, not as an AWG conversion.
- Using the wire diameter to check a stranded cable. AWG describes the conductor; stranding changes the overall outer diameter.
Frequently Asked Questions
Why is 14 AWG 1.628 mm and not a round number?
Because the standard is a geometric series, not a set of preferred numbers. Each gauge step multiplies diameter by 92^(1/39), about 1.1229, so the millimetre values never land on whole figures.
What is 14 AWG in mm² for cable shopping?
2.08 mm². Metric cable is sold in nominal sizes such as 1.5, 2.5 and 4 mm², so 14 AWG sits between the 1.5 and 2.5 sizes rather than matching either.
How many amps can 14 AWG carry?
Commonly 15 A for copper building wire at 60 °C, and up to 25 A for some high-temperature insulations in free air. Bundling, ambient heat and conduit fill reduce those figures, so the code table, not this conversion, decides.
Does a higher AWG number mean thicker wire?
No — the opposite. Larger gauge numbers are thinner: 18 AWG is 1.024 mm, 14 AWG is 1.628 mm and 10 AWG is 2.588 mm. Only 0 AWG and the 00/000/0000 sizes break the pattern by being thicker than AWG 1.
What is the formula in inches?
d (in) = 0.005 × 92^((36 − n)/39). For 14 AWG that is 0.005 × 12.82 = 0.0641 in, the same wire expressed in the units used on US spools.
