What 4-7-100-5% decodes to
First band 4, second band 7, multiplier ×100, tolerance ±5%: 4.7 kΩ, tolerance ±5%.
Read as digits: 4 and 7 form 47, then the multiplier adds two zeros — 4,700 Ω. The kΩ prefix is just a convenience for the same value.
How a four-band code is read
Band 1 is the first digit, band 2 the second, band 3 the multiplier, band 4 the tolerance. There is no third digit in a four-band code; the third band tells you how many zeros to append.
Worked example
Band 1 = 4
Band 2 = 7
Band 3 = ×100
(47 × 100) = 4,700 Ω = 4.7 kΩ
Band 4 = ±5%
The tolerance band matters as much as the value: ±5% on 4.7 kΩ is ±235 Ω, so anything from 4,465 to 4,935 Ω is in specification. A ±1% part would be within 47 Ω.
The colour table
- Black 0 · Brown 1 · Red 2 · Orange 3 · Yellow 4
- Green 5 · Blue 6 · Violet 7 · Grey 8 · White 9
- Gold ×0.1 and ±5% · Silver ×0.01 and ±10%
Which way round
Start from the end with the tolerance band — gold or silver, or simply the band with more space before it. A resistor with bands evenly spaced and no metallic band is ambiguous, and a multimeter is faster than guessing.
Mistakes worth avoiding
- Reading the multiplier as a third digit. 4-7-2 is 47 × 100, not 472 Ω.
- Confusing brown and red under poor light — 1 and 2 differ by a factor of ten in the multiplier position.
- Expecting a five-band code to read the same way; there the third band is a real third digit.
- Assuming the measured value must be exact. A 4.7 kΩ ±5% part reading 4.6 kΩ is correct.
Frequently Asked Questions
What is 47 × 100 in ohms?
4,700 Ω, which is written 4.7 kΩ. Two digits from the first two bands, then two zeros from the ×100 multiplier.
Which band is the tolerance?
The last one, usually gold (±5%) or silver (±10%), and often set slightly apart from the others. Brown is ±1%, red ±2%, and no fourth band means ±20%.
How do I read a five-band resistor?
Bands 1–3 are digits, band 4 is the multiplier and band 5 is the tolerance. A 4-band code has only two digits, so the same colours mean a different value.
What does ±5% mean in practice?
The true resistance is within 5% of the marked value — for 4.7 kΩ, between 4,465 and 4,935 Ω. That spread is normal and usually irrelevant in a circuit designed around it.
What if the resistor has only three bands?
The tolerance is ±20%, the default when no fourth band is printed. Three-band parts are older and less common.
What colours make 10 kΩ?
Brown, black, orange — 1 and 0 making 10, multiplied by 1,000 — with gold for ±5%. For 1 kΩ it is brown, black, red; for 100 Ω it is brown, black, brown. The first two bands stay the same; only the multiplier moves.
