What the defaults hold
A pipe of 2 inch internal diameter and 50 feet long holds about 8.2 US gallons, or 1.09 cubic feet.
The diameter must be the inside diameter. A “2 inch” pipe is nominally 2 inch outside with a wall thickness, so its bore is smaller — using the outside figure overstates the volume.
The pipe volume formula
A pipe is a cylinder, so its internal volume is the cross-sectional area times its length:
Volume = π × (Inner diameter ÷ 2)² × Length
A 2-inch pipe running 50 ft holds π × (2÷12 ÷ 2)² × 50 = 1.09 ft³, about 8.2 US gallons.
| Inner diameter | Volume per 50 ft | US gallons |
|---|---|---|
| 1 in | 0.27 ft³ | 2.0 gal |
| 1.5 in | 0.61 ft³ | 4.6 gal |
| 2 in | 1.09 ft³ | 8.2 gal |
| 3 in | 2.45 ft³ | 18.4 gal |
| 4 in | 4.36 ft³ | 32.6 gal |
Volume scales with the square of the diameter, so doubling the bore holds about four times as much. Related: water tank capacity and construction calculators.
The formula
Volume = π r² L, with r the inside radius and L the length in the same units. Then convert cubic feet to gallons at 7.48 gal/ft³.
Worked example: 2 in × 50 ft
Radius = 1 in = 1/12 ft = 0.0833 ft
Volume = π × 0.0833² × 50 = π × 0.00694 × 50 = 1.09 ft³
Gallons = 1.09 × 7.48 = 8.2 gal
Common pipe sizes per 10 feet
- ½ in — about 0.17 gal per 10 ft.
- ¾ in — about 0.38 gal.
- 1 in — about 0.68 gal.
- 2 in — about 1.63 gal.
- 4 in — about 6.5 gal.
Volume scales with the square of the diameter, so doubling the pipe size quadruples the water held — the most common surprise when estimating a drain-down or a glycol charge.
Why the inside diameter matters
Nominal pipe sizes are a historical label, not a measurement. A 2 inch schedule 40 steel pipe has an inside diameter of about 2.067 in, while schedule 80 is about 1.939 in — a 12% difference in volume for the same nominal size. For plastic pipe the wall is thinner and the bore closer to nominal.
Where the number is used
Sizing a drain-down, calculating antifreeze for a hydronic loop, working out flush volume for a water main, or estimating how much water a run of hose will waste before hot water arrives. Add the volume of fittings if the run has many elbows.
Frequently Asked Questions
Why 8.2 gallons for 50 feet of 2-inch pipe?
Because the internal volume is 1.09 cubic feet and a cubic foot holds 7.48 US gallons. 1.09 × 7.48 = 8.2.
Should I use the inside or outside diameter?
Inside. The wall thickness carries no water, and using the outside diameter overstates volume — sometimes by 12% or more on schedule 80 steel pipe.
How much does doubling the diameter change the volume?
It quadruples it. Volume goes with the square of the radius, so a 4 inch pipe holds four times a 2 inch pipe of the same length.
How many gallons per foot is 2-inch pipe?
About 0.163 gallons per foot, which is why 50 feet comes to 8.2 gallons. Halve the length and the volume halves.
Does the calculator include fittings?
No — straight pipe only. Elbows, tees and valves add a small amount each, worth allowing for on a long run with many bends.
How much water in 100 feet of 1-inch pipe?
A 1 inch inside diameter gives π × (0.5/12)² × 100 = 0.545 ft³, which is about 4.1 gallons. That is why flushing a long 1 inch line takes a couple of minutes before hot water arrives.
