Working out how to calculate water tank volume and capacity is easier with Water Tank Capacity, which answers as you type. Type Length (m), Width (m) and Height (m) into Water Tank Capacity; each keystroke re-runs the math. Water Tank Capacity prints the result and its working. That makes Water Tank Capacity handy for quick estimates anywhere. No sign-up is needed for Water Tank Capacity. The math runs on your device. Water Tank Capacity is part of the Construction collection on CalcProMaster, alongside water tank capacity, free online water tank capacity calculator and more. Keep Water Tank Capacity bookmarked for next time. No sign-up or email — Water Tank Capacity answers as you type.
What the defaults hold
A tank measuring 2 m by 1.5 m by 1 m holds 3 cubic metres, which is 3,000 litres — about 793 US gallons.
Use internal dimensions. Wall thickness on a concrete tank can be 100–200 mm a side, which is a 5–10% error on the volume before you have even filled it.
How tank capacity is calculated
For a rectangular tank, capacity is simply volume, converted to litres:
Capacity = Length × Width × Height, and 1 m³ = 1,000 litres
A 2 m × 1.5 m × 1 m tank: 2 × 1.5 × 1 = 3 m³ = 3,000 litres.
| Length | Width | Height | Volume | Litres |
|---|---|---|---|---|
| 1.0 m | 1.0 m | 1.0 m | 1.0 m³ | 1,000 L |
| 1.5 m | 1.0 m | 1.0 m | 1.5 m³ | 1,500 L |
| 2.0 m | 1.5 m | 1.0 m | 3.0 m³ | 3,000 L |
| 2.0 m | 2.0 m | 1.5 m | 6.0 m³ | 6,000 L |
| 3.0 m | 2.0 m | 2.0 m | 12.0 m³ | 12,000 L |
Leave headroom below the top so the tank can overflow safely. Related: pipe volume and construction calculators.
The formula
Volume = length × width × height, then multiply by 1,000 to convert cubic metres to litres.
2 × 1.5 × 1 = 3 m³. 3 × 1,000 = 3,000 L.
Worked example
Length 2.0 m
Width 1.5 m
Height 1.0 m
Volume = 3.000 m³
Capacity = 3,000 L ≈ 793 US gal ≈ 660 imperial gal
What 3,000 litres means in use
A typical household uses 300–500 litres a day, so this tank is roughly a week of storage. For fire reserve or irrigation the same figure applies — 3,000 L is 3,000 L whatever it is for.
Why the usable capacity is lower
- Freeboard. You never fill to the brim; an overflow and a lid clearance cost 5–10%.
- Outlet height. Water below the outlet cannot be drawn, which on a flat-bottomed tank is another few percent.
- Shape. A cylindrical tank uses πr²h, not length × width, and the difference is substantial at the same footprint.
- Structural displacement. Internal baffles or a sump reduce the stored volume.
Weight, which matters more than volume
Water is 1 kg per litre, so 3,000 L weighs 3 tonnes, plus the tank itself. That load has to be carried by the floor or roof structure — a filled tank on an upper floor is a structural question, not a plumbing one.
Frequently Asked Questions
How many litres is a 2 × 1.5 × 1 m tank?
Volume is 3 cubic metres, and each cubic metre is 1,000 litres — so 3,000 litres, or about 793 US gallons.
Should I measure inside or outside?
Inside. Wall thickness on a concrete or brick tank can be 100–200 mm, which is a significant fraction of the volume on a small tank.
How much does 3,000 litres weigh?
About 3 tonnes, since water is 1 kg per litre. Add the tank’s own weight and any platform before assessing what the structure can carry.
How long does 3,000 litres last a household?
Roughly a week at 300–500 litres a day. A single person might stretch it to two weeks; a large family with a garden could use it in three days.
How do I calculate a cylindrical tank?
Use π × radius² × height. A 1 m diameter, 2 m tall cylinder holds π × 0.5² × 2 = 1.57 m³, or 1,570 litres.
How many litres per metre of height in this tank?
The footprint is 2 × 1.5 = 3 m², so every metre of depth adds 3,000 litres. That is a useful way to check a partially buried tank: measure the water depth, multiply by 3,000 and you have the volume without knowing the total height.
