Moment of Inertia
Rotational inertia of common shapes
🔒 On-device · Method · · Disclaimer · Moment of Inertia
Need a fast answer on rotational inertia of common shapes? Moment of Inertia answers with the steps beside it. Enter Mass (kg) and Radius/Length (m) in any order — Moment of Inertia recalculates on every edit. Moment of Inertia prints the result and its working. Moment of Inertia replaces guesswork. No account is needed for Moment of Inertia. The browser does the arithmetic. Moment of Inertia handles moment of inertia calculator rotational inertia the same way as free online moment of inertia calculator — one of the Science tools on CalcProMaster. Run Moment of Inertia twice to find the driving input. Moment of Inertia is free, instant and local.
What the defaults give
A solid disk of 10 kg and 0.5 m radius has a moment of inertia of 1.2500 kg·m², from I = ½mr².
The mass distribution matters more than the mass. The same 10 kg shaped as a ring at the same radius gives 2.5 kg·m² — double — because all of it sits at the outer edge.
The formulas by shape
- Solid disk or cylinder (about its axis): I = ½ m r².
- Thin ring or hoop: I = m r².
- Solid sphere: I = ⅖ m r².
- Rod (about its centre): I = 1/12 m L².
Worked example: disk
m = 10 kg, r = 0.5 m
I = ½ × 10 × 0.5²
0.5² = 0.25, so I = 0.5 × 10 × 0.25 = 1.25 kg·m²
For the same inputs as a ring: I = 10 × 0.25 = 2.5. As a solid sphere: ⅖ × 10 × 0.25 = 1.0. The disk sits between them, which is what makes it the textbook default.
What the number is for
Moment of inertia is rotational mass: torque needed to spin something up is τ = Iα, and rotational kinetic energy is ½Iω². Double the inertia and the same torque takes twice as long to reach a given spin rate.
Where people go wrong
- Wrong axis. A rod spun about its end has I = ⅓mL², not 1/12; the value depends entirely on the axis, which the shape name alone does not fix.
- Radius versus diameter. Entering 500 mm as a 500 m radius produces an answer eight orders of magnitude out.
- Adding masses incorrectly. Inertias about the same axis add, so a motor plus its load is I₁ + I₂ — not the inertia of the combined mass at an averaged radius.
- Forgetting units. kg·m² only works if mass is in kilograms and length in metres.
Beyond the simple shapes
Real components are assemblies. Use the parallel axis theorem, I = Icm + md², to shift a body’s inertia to a different axis — a gearbox flange is rarely a thin disk about its own centre.
Frequently Asked Questions
Why is a disk 1.25 and a ring 2.5 for the same mass and radius?
Because a ring has all its mass at radius r, giving I = mr². A disk spreads mass inward toward the axis, where it contributes less, so half the ring’s value: ½mr².
What are the units?
kg·m² in SI, from mass in kilograms times length squared in metres. Using grams or centimetres without converting gives a value that is wrong by orders of magnitude.
Does a rod use its length or its radius?
Length — for a rod about its centre I = 1/12 mL². The third input is the length, not a radius, and about the end the coefficient changes to 1/3.
How does moment of inertia affect acceleration?
Directly through τ = Iα: for a given torque, doubling I halves the angular acceleration. In a motor-driven system the load inertia is usually expressed as a ratio to the motor’s own inertia.
What if my object is hollow?
Use the ring formula for a thin-walled cylinder. A thick-walled tube needs ½m(R² + r²), which sits between the disk and the ring values.
